ATIG400PR is a TIG welding power source specially designed for robots, which integrates wire feeding control, arc control, robotic interface, and other functions. ATIG400PR enjoys outstanding welding performance and high reliability.
Output
Input
Process
Materials
Share：
Multi-process: DC TIG /Pulse TIG
100% arc starting success rate: high-frequency arc starting cooperates with suitable arc striking current, outstanding arc striking performance
Short circuit protection: prevent tungsten electrode from sticking with the workpiece due to short circuit during welding
Multiple wire feeding modes: pulse simultaneous /constant speed wire feeding modes, realizing excellent welds formation
Stable wire feeding: 4-roll drive system+encoder speed feedback, realizing high-precision smooth wire feeding
Abundant robotic communication interfaces: it can achieve CAN /485 /DEVICENET /ETHERNETIP /ETHERCAT /PROFINET and other digital communication through digital interface box, and human-machine control through analog and switching value
1 Power source
1 Connected primary cable L=3m
1 Ground cable L=3m
1 Wire feeder
1 Wirefeeder control cable L=5m
1 TIG Torch
1 Wire Spool
1 Guide hose
1 Analog communication cable
1 Welding torch liner
