Matching Welding Machine

‹

ATIG-315PAC-R

›

‹

  • ATIG-315PAC-R

›

ATIG-315PAC-R

ATIG-PACIII-R series is fully digital models with high end DSP technology, suitable for both automatic application and manual welding. Compared with ATIG-PAC series, it offers advanced wave control technology which brings more flexibility for thinner /thicker material during critical alumumium welding. Smart parameters adjuestment brings cleanest, deepest penetration and perfect welding result for high welding quality demanding.


Output t34.png acdc.png 微信图片_20220317091517.jpg      Input t39.png  60 .png         Process t19.png  微信图片_20220317095739.png


Materialst57.png t46.png t45.png t51.png t49.png                                               20210929155043253.jpg@!jw1200  20210929155047718.jpg@!jw1200


Share：

Inquiry
Features
Specification
Application
Accessories
Download

  • Multi-process: AC TIG /DC TIG /Pulse TIG

  • Multi-waveform of AC TIG: square waveform, sine waveform, mixed waveform

  • 100% arc starting success rate: high-frequency arc starting, cooperating with arc starting current, outstanding arc starting performance

  • Short circuit protection: prevent tungsten electrode from sticking with workpiece due to short circuit during welding

  • Multiple wire feeding modes: pulse simultaneous /constant speed wire feeding modes, realizing excellent welds formation

  • Stable wire feeding: 4-roll drive system+encoder speed feedback, realizing high-precision smooth wire feeding

  • Save and recall 10 sets of customized parameters

  • Abundant robotic communication interfaces: it can achieve CAN /485 /DEVICENET /ETHERNETIP /ETHERCAT /PROFINET and other digital communication through digital interface box, and human-machine control through analog and switching value



ATIG315PAC-R
Rated input voltage/frequency (Hz)3 phase, 480V±10%, 60Hz
Rated input capacity (KVA)13.6
Rated input current (A)17.7
Duty cycle (40̊C)60%@315A
OCV (V)(MMA /TIG)45/79
TIGDC TIGOutput current range (A)5-315
Pulse TIGPulse frequency (Hz) (AC /DC)0.2-250 /0.2-999
Peak current (A)5-315
Base current (A)5-315
Pulse duty cycle15%-85%
AC TIGWave formSquare, Irregular square, Sine
AC frequency (Hz)40-250
AC balance-50%~+40%
MixtureFrequency (Hz)0.5-10
Duty cycle15%-85%
Pre-gas /post gas (s)OFF-10 /OFF-60
Initial /final current (A)5-315/5-315
Up-slope /down-slope (s)OFF-10 /OFF-15
Trigger mode2/4T, Repeat, Spot
Arc ignition methodHF /Contact
Job channels10
InterfaceAnalog communication /Devicenet, CAN, 485, digital communication
Dimension (mm)655*324*546
Weight (kg /lb)53 /117


ATIG315PAC III.jpg
