ACUT-120a

ACUT-a series is invented for professional use in heavy duty application with CNC system. ACUT-a series can be integrated with CNC system and have special non HF ignition for best arc start. ACUT-a series can show best result for cutting steel with thickness up to 15 mm.


Output t34.png t33.png t58.png       Input t39.png  60 .png       Process t27.jpg


Materials t45.png t46.png t47.png t48.png                                          20210929155043253.jpg@!jw1200  20210929155047718.jpg@!jw1200

Share:

Inquiry
Features
Specification
Application
Accessories
Download
  • Light in weight: inverter technology makes it easy to be maintained or carried

  • 60% duty cycle: non-stop work with full power, air-cooled power source

  • Multiple applicable materials: carbon steel, stainless steel, copper, aluminum, and others

  • Highly reliable: self-diagnosis function and multiple protections

  • Friendly for plasma torch: post flow for additional cooling of plasma torch

  • Best choice for CNC plasma cutting system: the special non-HF ignition ensures the best arc starting

  • Highly stable: the expanded service life of the fan and reduced fault rate owing to the smart fan feature


ACUT120a
Rated input voltage/frequency (Hz)3 phase, 480V±10%,60Hz
Rated input capacity (KVA)16.5
Rated input current (A)19.8
Duty cycle (40̊C)60%@120A
OCV (V)340
Output current rang (A)30-120
Arc ignition methodLF (low frequency)
Maximum cutting thickness (mm)35
Clean cut thickness (mm)1-15
Air pressure (Mpa)0.8
Protection classIP21S
Insulation classH
Dimension (mm)621*311*557
Weight (kg /lb)43.5 /96.1



ACUT 120A.jpg


  • 1 Power source

  • 1 Connected primary cable L=3m

  • 1 Ground cable L=3m with clamp and quick plug

  • 1 Pressure-reducing valve

  • 1 Plasma torch
